Optical patchcord monomode SC/APC-SC/APC Simplex Ø1,7mm
€3,33 – €4,68 (Price exclusive of tax)
Premium single mode optical patchcord.
- SC/APC 8° connector on both ends
- Monomode fiber
- Yellow LSZH jacket
- Ø1,7mm
Custom patchcords on demand.
Description
The SC patchcords are manufactured according to JIS, IEC, EIA/TIA and ANSI specifications for intermateability and optical performance. The SC patchcords are offered for both SM applications, with PC and APC polishing method. All connectors now come with the laser printed OPTOKON logo and patchcord cables are produced by OPTOKON Kable factory, have a LSZH (Low Smoke Zero Halogen) cable jacket, and are bend insensitive ITU-T G.657.A1 fiber.
Specifications
| Specifications | SM Ultra PC grade C |
| Insertion loss | 0.25 dB typ |
| 0.50 dB 97% | |
| Return loss (RL1) (IEC 61300-3-6) | > 60dB |
| Strain relief | 100 N2 |
| Operating temperature | -40°C to +85°C2 |
| Durability | min 1000 cycles |
| Assembly procedure | glue and polish |
| Connection | physical contact |
| Lock mechanism | snap-on |
| Standards | ISO/IEC 11801, TIA 568A, IEC 61755-4, EN-50377-4 |
| Ferrule material | full ceramic zirconia |
| Connector material | thermoplastic, zinc alloy nickel plated |
| Adapter material | polymer composite, zinc alloy |
| Length | 1m, 2m, 3m, 4m, 5m, 7m, 10m |
|---|
